SKU: GR8180124.00
Direct Procurement & RFQ
Direct online checkout is disabled on Liber Holdings. For volume discounts, blanket purchase agreements, and fast shipment, submit an RFQ or call our corporate sales desk.
Technical Specifications
Verified Specs
| Serie |
GR Series - Ironman Worm Gear Reducers
|
| Product Type |
Worm Speed Reducer
|
| Housing Material |
Cast Iron
|
| Product Line |
GR Series - Ironman Worm Gear Reducers
|
| Gear Type |
Worm
|
| Input Style |
C-Face Quill
|
| Output Torque Rating (in-lb) |
571
|
| Relación |
15:1
|
| Ratio Range |
15:1
|
| Output Shaft |
Solid Shaft
|
| Output Diameter (in) |
0.875
|
| Output RPM |
116
|
| Service Factor |
1
|
| Series Code |
GR
|
| HP Range |
1 to 1-1/2 (< 2)
|
| Mounting Style |
Base
|
| Output Torque Range |
500 to 1000 in lbs
|
| Center Distance (in) |
1.75 1.75
|
| Output Shaft Direction |
Right
|
| Reduction |
Single
|
| Input RPM |
1750
|
| Input Diameter (in) |
0.625
|
| Center Distance Range |
1" thru 3.25"
|
| No. of Gear Reductions |
Single
|
| Assembly |
BMQ-R
|
| Output Key |
3/16 X 1.38
|
| Output Shaft Assembly Code |
R
|
| Reducer |
Worm - Right Angle
|
| Model Code |
BMQ818
|
| Shaft Seal Material |
Viton
|
| Input HP |
1.224
|
| Motor Frame Size |
56C
|
| Input HP @ 1750 RPM |
1.224
|
| Output HP |
1.058
|
| Reducer Style |
Worm - Right Angle
|
| Input Bore (C Face) |
0.625
|
| Input Keyway (C Face) |
3/16 x 3/32
|
| Output Style |
R
|
| Thrust Rating - output shaft |
1144
|
| Overhung Load Rating (Output Shaft(lb)) |
1200
|
| Output Shaft Orientation |
R
|
| Series Style |
GR-BMQ-R
|
| Frame Size |
56C
|
| Keyway |
3/16 X 3/32
|
| Series Type |
Cast Iron 800 Worm Gear Reducers
|
| Input Quill Diameter (in) |
0.625
|
| Overhung Load |
1200
|
| TAP Depth |
0.63
|
| H-Tap size |
5/16-18 UNC
|
Multi-State Hub Fulfillment
Stocked & fulfilled through RBC Industrial (El Paso, TX) and Tooling Components (Union City, PA).
